Brand:
Yamaha
|
|
Radio:
FM
,
DAB+
|
|
STANDBY POWER CONSUMPTION:
0.5 W
|
|
DIMENSIONS:
435 x 141 x 322 mm; 17-1/8” x 5-1/2” x 12-5/8”
|
|
FREQUENCY RESPONSE:
20Hz-20kHz (0+/-0.5db), 10Hz-100kHz (0+/-3.0db)
|
|
BLUETOOTH:
Yes (SBC / AAC)
|
|
Weight:
6.7 kg; 14.8 lbs.
|
|
Maximum Power (4 ohms, 1kHz, 0.7% THD, for Europe):
115 W + 115 W
|
|
High Dynamic Power/Channel (8/6/4/2 ohms):
125 W / 150 W / 165 W / 180 W
|
|
Signal-to-Noise Ratio (CD):
100 dB (S: 500 mV)
|
|
Minimum RMS Output Power (8 ohms, 40Hz～20kHz):
100 W + 100 W (0.2% THD)
|
|
Total Harmonic Distortion (8 ohms, 20 Hz-20 kHz):
0.025% (Phono (MM) to REC Out), 0.2% (CD to SP Out)
|
|
Input Sensitivity (CD):
500 mV / 47 k-ohms
|
|
FM 50dB Quieting Sensitivity (IHF, 1 kHz, 100% Mod., Mono):
3 μV (20.8 dBf)
|
|
FM Signal-to-Noise Ratio (Mono/Stereo):
72 dB / 70 dB
|
