Merk:
Yamaha
|
|
STANDBY POWER CONSUMPTION:
0.5 W
|
|
DIMENSIONS:
435 x 151 x 387 mm; 17-1/8” x 6” x 15-1/4”
|
|
FREQUENCY RESPONSE:
10 Hz-100 kHz +/-1.0 dB
|
|
Weight:
11.2 kg; 24.7 lbs.
|
|
Minimum RMS Output Power (8 ohms, 20 Hz-20 kHz):
100 W + 100 W (0.019% THD)
|
|
Maximum Power (4 ohms, 1kHz, 0.7% THD, for Europe):
160 W + 160 W
|
|
High Dynamic Power/Channel (8/6/4/2 ohms):
140/170/220/290 W
|
|
Damping Factor:
240
|
|
Total Harmonic Distortion (CD to Sp Out, 20 Hz-20 kHz):
0.019% (50 W/8 ohms)
|
|
Signal-to-Noise Ratio (CD):
99dB (input shorted, 200 mV)
|
|
Audio In / Out:
8 / 2
|
|
Digital input:
Yes (optical / coaxial)
|
|
Subwoofer Out:
Yes
|
|
Pure Direct:
Yes
|
|
DC out:
Yes
|
|
ToP-ART:
Yes
|
|
Power Management (Auto Power Standby):
Yes
|
|
Switchable CD Direct Amplification:
Yes
|
