Marque:
Onkyo
|
|
Weight:
21.7 lb (9.8 kg)
|
|
Dimensions:
17 1/8˝ x 6 13/16˝ x 14 15/16˝ (435 x 173.5 x 379.5 mm)
|
|
Frequency Response:
10 Hz–100 kHz/+1 dB, -3 dB (Direct/Pure Audio)
|
|
Power output (All channels):
210 W/Ch (6 ohms, 1 kHz, 10% THD,1-ch driven) 100 W/Ch (8 ohms, 20 Hz–20 kHz, 0.08% THD, 2-ch driven, FTC)
|
|
Dynamic power:
240 W (3 ohms, Front) 210 W (4 ohms, Front) 120 W (8 ohms, Front)
|
|
THD+N (Total Harmonic Distortion + Noise):
0.08% (20 Hz–20 kHz, half power)
|
|
Input sensitivity and impedance:
200 mV rms/47 k-ohms (Line) 3.5 mV rms/47 k-ohms (Phono MM)
|
|
Rated RCA output level and impedance:
1 V rms/470 ohms (Subwoofer pre-out) 200 mV rms/470 ohms (Zone 2/Zone B line-out)
|
|
Tone control:
±10 dB, 20 Hz (Bass) ±10 dB, 20 kHz (Treble)
|
|
Signal-to-noise ratio:
106 dB (Line, IHF-A) 80 dB (Phono, IHF-A)
|
|
Speaker impedance:
4–16 ohms
|
|
Power consumption (operating):
635 W
|
|
Power consumption (standby):
0.1 W
|
